TCM technology 3 ton and 3.5 ton new forklift prices with 1220mm fork length
Features of new forklift prices
1. Physical appearance: Fork lift truck has brilliantly repeated streamline surface modeling and sharpening of shapes to required specification. It has a luxurious appearance, flowing and richly dynamic lines of finishes.
2. Engine hood: A high quality and high stiffness integral GRP hood. Has greater performance in sound proofing and effective heat insulation effects.
3. Hydraulic system: Selected from the best qualified and reliable hydraulic component manufacturer that vastly implements advanced technology. It has good performance by sealing fuel tank structure and multi-function valve with forward self-locking
4. Introduces new technology by using good reliability hand brakes with brake master cylinder and brake light.
5.. Wide base tires at the front: improves the bearing capacity, prolong tire life-span and improve machines stability.
Specifications of new forklift prices
| Features | Manufacturer | | | LTMG |
| Model | Power shift T/M | FD35T |
| Manual shift T/M | FD35C |
| Operator type | | | Driver/seat |
| Tire type | Front/rear | | Pneumatic |
| Wheel | Front/rear | | 2/2 |
| Dimension | Max. lifting height | | mm | 3000 |
| Free lift | | mm | 150 |
| Fork size | L*W*T | mm | 1070*125*50 |
| Tilt range | Mast forward/backward | deg | 6/12 |
| Overall length(without fork) | | mm | 2760 |
| Total width | | mm | 1285 |
| Mast height (fork lowering) | | mm | 2075 |
| Overall height fork raised | With backrest | mm | 4250 |
| Height to head guard | | mm | 2140 |
| Turning raduis(outside) | | mm | 2495 |
| Front face of fork to front axle | | mm | 485 |
| Min. right angle stacking aisle | | mm | 2975 |
| without load length&clearence |
| Performance | Speed | Max Travelling | km/h | 18/19.5 |
| full/no load |
| Lifting | mm/s | 450/500 |
| full/no load |
| Lowering | mm/s | 450/420 |
| full/no load |
| Max.drawbar pull | Power shift T/M | kg | 2100/1000 |
| full/no load |
| Manual shift T/M | kg | 2100/1000 |
| full/no load |
| Gradeability at 1.6km/h | Power shift T/M | % | 18/20 |
| full/no load |
| Manual shift T/M | % | 18/20 |
| full/no load |
| | Weight distribution | Full load front/rear | kg | 7380/900 |
| No load front/rear | kg | 1820/2960 |
| Frame | Tires | Number | front/rear | 2/2 |
| Model | front axle | 28x9-15-12PR |
| rear axle | 6.50-10-10PR |
| Tread | Front/rear | mm | 1060/970 |
| Ground clearence | At lowest point(mast) | mm | 120 |
| Frame | mm | 135 |
| Brake | Service brake | | Hydraulic-foot pedal |
| Parking brake | | Mechanical-hand lever |
| Engine | Battery | Voltage/capacity | V/AH | 12/80 |
| Engine | Model | | ISUZU 4JG2 |
| Rated power | kw/rpm | 44.8/2450 |
| Rated torque | N.m/rpm | 186/1800 |
| Number of cylinders | | 4 |
| Placement | L | 3.059 |
| Fuel tank capacity | L | 70 |
| Transmission | Speed forward/backward | Power shift T/M Manual shift T/M | 1-1 power shift T/M |
| 2-2 manual shift T/M |
| Operating pressure | Hydraulic system pressure | kg/cm² | 180 |
new forklift prices
After-sale service
Nowadays we have been sell more than 100 countries. All the products of LTMG supplied withone year or 2000 working hours (which occurs first) period quality warranty.
If the machine have any problem within the warranty time, but not caused by man-made, we will send you spare parts for free.
Detail clauses and policies please see to our website and product's quality certificate.
Our company
FAQ:
1.What Certificate do you have?
LTMG workshop meet with the ISO9001:2008 Quality System.
All of our products with CE certificate. Some of our products meets the EPA requirements.
2. Can you customize and design as the clients' requirement?
LTMG will try its best to meet all kinds of clients' special requirements.
However, All the customizing and refit should be implemented safely and scientifically.
The colors can be painted as client's need.
3.How long is the warranty of your products?
Normally 1 year or 2000 working hours whichever occurs first. Details to see the LTMG warranty policy for each model.
4. Can you produce the products labeled with the client's brand?
With the authorization of the brand, we can OEM for our clients.
5. What payment terms do you accept?
Normally 30% T/T in advance as deposit, blance paid before shipment.
100% L/C at sight issued by world famous bank with good faith is also available.
6.Delivery time:
Standard configuration products are always in stock.
The production period of Customizing products is 30 days.
